Mechanical Limit Switch

Name: Mechanical Limit Switch
Brand: Prestige Valves

Limit switches, positioners, gearboxes, manual overrides, solenoid valves and air filter regulators.

Enquire about this product View catalogue page

PRODUCT / TECHNICAL DETAILS

Specifications.
For this configuration.

Mechanical Limit Switch catalogue specifications
Body Material	Die Cast Aluminium Alloy, Polyster Powder Coating.
Connection	2XM20 Cable Entries.
Shaft Material	Stainless Steel.
Limit Switch Type	2 x SPDT Mechanical.
Voltage/ amps	250VAC, 125VAC, 250VDC/0.3A, 125VDC/0.6A, 30VDC/10A.
Temperature	-20DegC to 70 DegC.
Enclosure Rating	Weather Proof IP 67.
Mounting Bracket	CS or SS.

Spares available on request. Materials, operating limits, connections and automation options depend on the selected configuration. Share your application so the team can confirm the requirements.
Source: supplied Prestige catalogue, PDF page 18.

Read the original catalogue specification text

Source title: Mechanical Limit Switch

Body Material: Die Cast Aluminium Alloy, Polyster Powder Coating. Connection: 2XM20 Cable Entries. Shaft Material: Stainless Steel. Limit Switch Type: 2 x SPDT Mechanical. Voltage/ amps: 250VAC, 125VAC, 250VDC/0.3A, 125VDC/0.6A, 30VDC/10A. Temperature: -20DegC to 70 DegC. Enclosure Rating: Weather Proof IP 67. Mounting Bracket: CS or SS.

Supplied photographs: Original view 01
